The low working platform ensures the stability of 150 ton removable gooseneck trailer with dolly’s transportation and is suitable for carrying various types of construction machinery, large equipment and steel.
Major parts and components of the 150 ton removable gooseneck trailer with dolly are processed by advanced equipment.
Dangote 150 Ton Removable Gooseneck Trailer with Dolly for Sale | Rgn Lowboy Trailer
Dangote 150 Ton Removable Gooseneck Trailer with Dolly for Sale | Rgn Lowboy Trailer
Dangote 150 Ton Removable Gooseneck Trailer with Dolly for Sale | Rgn Lowboy Trailer
Dangote 150 Ton Removable Gooseneck Trailer with Dolly for Sale | Rgn Lowboy Trailer
Overall dimension: 17900mm * 2500+250*2mm *2200mm(platform 800mm)
Loading capacity: 150 ton
Rng lowboy trailer axles：4 axles with 2 axles dolly
Tire: 16 units, 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension or air suspension
Spring leaf: 120(W)mmx16(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Removable gooseneck trailer tire weight: About 9.5-19T
Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.
Bottom Platform: 5mm thick, checkered plate
Hydraulic cylinder: 12KW diesel engine with hydraulic station
Removable gooseneck trailer ramp: spring or hydraulic type
Removable gooseneck trailer ABS: Optional
Removable lowboy trailer valve: WABCO valve
Light: LED light (specially intended for oversea markets)
lowboy gooseneck trailer voltage: 24V
Detachable lowboy trailer for sale tool box: 1 set
Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust
