According to the total volume and the number of compartments, as well as the tri axle semi trailer fuel tanker position and volume of each bin, the sedimentation cup and diversion groove are designed. The professional design ensures fast oil unloading speed and improves work efficiency while also ensuring the oil residue is the least, and the benefit is maximized.
Tri Axle Semi Trailer Fuel Tanker for Sale | How Much Does a Fuel Tanker Hold
Tri Axle Semi Trailer Fuel Tanker for Sale | How Much Does a Fuel Tanker Hold
Tri Axle Semi Trailer Fuel Tanker for Sale | How Much Does a Fuel Tanker Hold
Tri Axle Semi Trailer Fuel Tanker for Sale | How Much Does a Fuel Tanker Hold
Dimension: 10600mm * 2550mm *3750mm
Total volume(L): 45000 Liters
Tank Body Material: Q235 carbon steel
End plate: Q235 carbon steel
Manhole Cover: Carton steel
Bottom Valve: Aluminum API Pneumatic Bottom Valve
Compressor: BOHAI 10m³/12m³ or other brands
Discharging Valve: Diameter is 3 or 4 inch
Compartments: Single Compartment
Discharging Pipe: 4 inch rubber hose,2pcs,6m/each
Cat Walk: With (common model or special design)
Main beams: Welded design or special design I beam, connected by bolts and nuts Q345 carbon steel material
Axle: 3 axles,13T,FUWA
Landing Gear: JOST(D200T) or China brand 28T
Kingpin: JOST 2.0 or 3.5 inch bolt-in king pin
Suspension: Mechanical suspension
Leaf Spring: 90(w)mmx13(thickness)x10layers or 10mm x12mmx12 layers
Pneumatic Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tank
Rim: 9.00-22.5Chinese brand
Tire: 12.00R22.5
ABS: Optional
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layer of top coats.
Accessories: One standard tool box
Shipping Terms: By bulk cargo, RORO or 40HQ containers
