The 45 ton container side lifter trailer is a container-specific loading and unloading trailer, which is used in container terminals and transfer yards. The role of container loading trailer is to realize container handling, such as loading and unloading of 40ft sideloader trailer, side lifters for sale.
Container Side Lifter | 45 Ton Container Loading Trailer for Sale - Dangote Trailer
Container Side Lifter | 45 Ton Container Loading Trailer for Sale - Dangote Trailer
Container Side Lifter | 45 Ton Container Loading Trailer for Sale - Dangote Trailer
Max. lifting capacity: 45Ton
Max.stabilizer outreach: 3200mm
Max.working range: 4000mm
Overall height: 2500mm
Overall length: 1020mm
Max.pressure of hydraulic system: 28Mpa
Dimension(L*W*H): 14100*2500*4200mm
Axle: 3 axle* 13 ton (220mm brake pads)
Tire: 12 pcs, 12R22.5
Suspension: Heavy-duty type mechanical spring suspension
Kingpin: 3.5-inch bolted type
Braking system: WABCO Emergency valve
Landing gear: JOST
Tow Chain: lgus (imported)
Power source: Power take-off (equipped)
Hydraulic pump: Gear type Casappa Italy
Direction control valves: AMCA Holand
Remote Control: NBB Germany
