Dangote 120 ton detachable gooseneck lowboy trailer with tires exposed by this to reduce the height of the low bed. 120 ton detachable gooseneck lowboy trailer need more strong and stability of the 120 ton detachable gooseneck lowboy trailer with lower gravity when transporting.
Dangote Heavy Duty Hydraulic 120 Ton Detachable Gooseneck Lowboy Trailer for Sale
Dangote Heavy Duty Hydraulic 120 Ton Detachable Gooseneck Lowboy Trailer for Sale
Dangote Heavy Duty Hydraulic 120 Ton Detachable Gooseneck Lowboy Trailer for Sale
Overall dimension：17000mm * 3000mm *2500mm
Loading capacity: 120 ton
Axles：2 lines 4 axles
Tire: 216 units, 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension
Spring leaf: 120(W)mmx16(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Tare weight: About 9.5-19T
Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.
Bottom Platform: 5mm thick, checkered plate
Hydraulic cylinder: 12KW diesel engine with hydraulic station
Ramp: spring or hydraulic type
ABS: Optional
Valve: WABCO valve
Light: LED light (specially intended for oversea markets)
Voltage: 24V
Tool box: 1 set
Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust
